Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Brand Name: | Gempump |
| Certification: | IOS9001,CE |
| Model Number: | 40PV-SPGEM |
| Minimum Order Quantity: | 1 set |
| Price: | USD 1000/Set |
| Packaging Details: | Ply wooden case |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 sets per month |
| Product: | Vertical Non-Clogging Submersible Pump | Theory: | Centrifugal Pump |
|---|---|---|---|
| Material: | High Chrome Alloy | Warranty: | 1 Year |
| Place Of Origin: | Shijiazhuang,China | Power: | Electric Motor |
| Voltage: | AC380V/AC400V/AC415V | Certification: | CE,ISO9001 |
| High Light: | 40% Efficiency Sewage Slurry Mud Pump,Non Clogging submersible sludge pump,Non Clogging Sewage Slurry Mud Pump |
||
Heavy Duty Vertical Non-Clogging Submersible Solid Centrifugal Vertical Slurry Sludge Pump
SP series Submersible slurry Pump is cantilevered, vertical, submersible slurry pumps.
Features :
1. SP (R)GEM type submerged pumps are vertical centrifugal slurry pump, generally into the pool or pit to
work,used to transport abrasive, coarse particle, high concentration slurry.
2. Don't need any shaft seal and shaft seal water, in the inhaled volume insufficient conditions they can also work normally.
3. SP (R)GEM type submerged pumps' pump body is made of wear-resisting metal. Impeller is made of wear-resistant metal or rubber, polyurethane SP (R)GEM type submerged pumps parts into the liquid with rubber lining,they are all applicable to transport corrosive slurry.
Vertical Slurry Pump Features
-The rotor parts can be adjusted axially and supported by multiple points, so heavy duty cantilever sump pump can operate steadily and reliably.
-The slurry pump adopts a long shaft structure and can be inserted up to 10 meters deep. Shaft coupling is safe and reliable. Convenient disassembly.
-The impeller is immersed in the medium when the pump starts, so it is easy to start, and there is no air exhaust problem.
-The outlet flange is a half movable flange for easy connection
Vertical Non-clogging Slurry Pump Application
●Mineral processing
●Coal preparation
●Chemical processing
●Effluent handling
●Sand and gravel
●Tank, pit or hole-in-the-ground slurry handling situation
SPGEM SUMP PUMP PERFORMANCE PARAMETERS
| Type | Allowable Mating Max. Power(Kw) | Range Of Performance | Impeller | |||||
| Capacity/Q | Head/m | Speed/rpm | Max Efficiency/% | No. of Vanes | Impeller Diameter/mm | |||
| m³/hr | L/S | |||||||
| 40PV-SPGEM | 15 | 19.44-43.2 | 5.4-12 | 4.5-28.5 | 1000-2200 | 40 | 5 | 188 |
| 65QV-SPGEM | 30 | 23.4-111 | 6.5-30.8 | 5-29.5 | 700-1500 | 50 | 5 | 280 |
| 100RV-SPGEM | 75 | 54-289 | 15-80.3 | 5-35 | 500-1200 | 56 | 5 | 370 |
| 150SV-SPGEM | 110 | 108-479.16 | 30-133.1 | 8.5-40 | 500-1000 | 52 | 5 | 450 |
| 200SV-SPGEM | 110 | 189-891 | 152.5-247.5 | 6.5-37 | 400-850 | 64 | 5 | 520 |
| 250TV-SPGEM | 200 | 261-1089 | 72.5-302.5 | 7.5-33.5 | 400-750 | 60 | 5 | 575 |
| 300TV-SPGEM | 200 | 288-1267 | 80-352 | 6.5-33 | 350-700 | 50 | 5 | 610 |
Gempump is one of professional factory of slurry pump, sand gravel pump , dredging pump , Water pump and spare parts .
GemPump is devoted to pump solution industry for more than 10 years!
The Pumps are widely used in in metallurgy, mining, Nonmetallic Mining, Coal, Energy resources, Sand mining, Dredging, Environmental protection, Petrochemical engineering, Flue gas desulfurization and other industrial departments.
The Pumps are exported to USA, Canada, Germany, Russia , Australia, South Asia, North America, South Africa, and etc , up to more than sixty countries.
