Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Certification: | ISO9001 CE |
| Model Number: | 6/4D-G |
| Minimum Order Quantity: | 1 set |
| Price: | 1000 USD/SET |
| Packaging Details: | Ply wooden box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 SET/Month |
| Application: | River / Sea Sand Dredging | Driven Power: | Motor/Diesel Engine |
|---|---|---|---|
| Wet Parts: | Chrome Alloy | Warranty: | 1 Year |
| High Light: | 1400rpm Gravel Sand Pump,6/4D-G Gravel Sand Pump,6/4D-G Dredging Sand Pump |
||
Technical parameters of Big Particle Sand Gravel Pump
| Gravel Pump Model | 6/4D-G |
| Inlet/Outlet size | 150mm/100mm |
| Capacity | 39-250m3/h |
| Head | 7-50m |
| Speed | 600-1400rpm |
| Max. Power | 60KW |
| Max.Solid | 82mm |
| NPSH. | 2.5-3.5m |
| Seal type | Gland packing,Expeller,Mechanical |
Gravel sand pump application:
Gravel pumps are designed for continuously handling the most difficult higher abrasive slurries
which contain too big solids to be pumped by a common pump.
Dredging, suck gravel in the dredger, suck gravel in the course of rivers
Delivering slurries in mining, explosive sludge in metal smelting
Type GH pumps are of high-head ones
Gravel sand pump description:
1. G(GH) pump is horizontal cantilevered single-casing centrifugal pump.
2. G type pump adopts clamp bands clamping pump body and the cover of the pump
3.the discharge direction of pump can be oriented in any direction of 360.
4.The wet-parts are made of Ni-hard and high chromium alloys.
5. Bearing components use cylindrical structure, easy to adjust the gap between the impeller and pump body.
It can be removed in the way of the whole when maintenance.Bearing adopt oil lubrication.
6.Shaft seal: packing seal, expeller seal,mechanical seal
