Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Brand Name: | Gempump |
| Certification: | ISO9001,CE |
| Model Number: | 14CQ-5 |
| Minimum Order Quantity: | 1 set |
| Price: | 1000 USD/Set |
| Packaging Details: | Wooden box |
| Delivery Time: | 5 days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union |
| Supply Ability: | 1000Sets Per Months |
| Type: | SS304 316L Magnetic Pump | Pressure: | High Pressure |
|---|---|---|---|
| Material: | SS304 SS316L | HS Code: | 841311000 |
| Application: | Discharge Process Pump, Circulating Pump | Warranty: | 12 Months |
| Voltage: | 220V/380V/415V | Temperature: | -80c To +150c |
| Standard: | ASME, CE , ASNI | Motor: | Exproof |
| High Light: | high temperature magnetic drive centrifugal pump,ss 316l magnetic drive centrifugal pump,ss304 magnetic centrifugal pump |
||
High Temperature SS304 316L Stainless Steel Sea Acid Alkali Chemical Magnetic Process Dosing Pumps
Stainless Steel Magnetic Pump Product Description:
CQ magnetic drive pump is a seal-less centrifugal pump. It is the best selling and most popular product in Tengyu. CQ pump is very cost effective, easy to use and maintain. It has relatively simple structure, so it is very easy to repair or change wearing parts. There are various stainless steel type(321, 304, 316, 316L) can be choosed according to the different medium.
This pump is featured by simple structure, appealing profile, small volume, low noise, reliable running, easy operation and maintenance, and etc, its magnetic-driven part uses ferrite as main material, provided with competitive price, it is the most widely-used leak-tight pump at present.
Capacity: 15-850L/min
Head: 2-50m
Medium temperature: ≤ +80degree
Ambient temperature: ≤ +40degree
System Max Operating Pressure: ≤ 1.6MPa
Anti Acid Alkali Chemical Magnetic Drive Centrifugal Pump Character:
1. Using the one of the world's most outstanding hydraulic model to reduce energe consumption.
2. Using the high magnetic perormance of permanent magnetic material to ensure enough magnetic torque.
3. The lower eddy current insulation sleeve design gives higher efficiency to the pump.
4. The specially designedlubrication cooling system and the automatic balance of axial force ensure the safe operation of the pump.
5. The sliding bearing is made of superior material and with the advanced hydrodynamic lubrication structure, the reliability of the pump and the life of the bearing are guaranteed.
6. Equipped with liquid break and overload automatic stop device, which can effectively prevent the magnetic pump idling dry grind and motor overload.
High Temperature Magnetic Process Dosing Pump Typical Uses:
1. Magnetic pump has advantage of compact structure, good- looking appearance, small volume, low noise, work reliable and easy to manage. It can be widely use for taking out acid, alkali liquid, oil type, rare valued liquid, volatile liquid and circular water equipment, filter accessories of chemical and industry, pharmacy, petroleum, galvanization, food-staff, film and television development, scientific research institution, National defense industry. Especially it is very suit for the take-out of leakiness, combustible, explosive liquid.
2. Corrosive liquid without solid particles, acids, alkalis, alcohol, bleach, photography solution, nitric acid, hydrochloric acid, hydrofluoric acid, acetic acid, sodium hydroxide, acetone, 4 ethylene oxide, water, salt and so on.
3. Enter the medium temperature -15~ +100, made of stainless steel, the density is not greater than 1600kg/m3, suction pressure is less than 0.2Mpa, the maximum working pressure of 1.3Mpa, transmission fluid without particles and fibers.
Major parts material form:
Stainless Steel Mag Drive Horizontal Centrifugal Pump Data Sheet
| Model | Inlet | Outlet | Head | Flow | Power | Speed |
| (mm) | (m) | (m3/h) | (Kw) | (rmin) | ||
| 14CQ-5 | 14 | 12 | 5 | 1.2 | 0.12 | 2900 |
| 16CQ-8 | 16 | 12 | 8 | 1.8 | 0.18 | 2900 |
| 20CQ-12 | 20 | 14 | 12 | 3 | 0.37 | 2900 |
| 25CQ-15 | 25 | 20 | 15 | 5.4 | 1.1 | 2900 |
| 32CQ-15 | 32 | 25 | 15 | 6.6 | 1.1 | 2900 |
| 32CQ-25 | 32 | 25 | 25 | 4.8 | 1.1 | 2900 |
| 40CQ-20 | 40 | 32 | 20 | 10 | 2.2 | 2900 |
| 40CQ-32 | 40 | 32 | 32 | 11.5 | 4 | 2900 |
| 50CQ-25 | 50 | 40 | 25 | 14.4 | 4 | 2900 |
| 50CQ-32 | 50 | 40 | 32 | 13.2 | 4 | 2900 |
| 50CQ-50 | 50 | 32 | 50 | 7.8 | 5.5 | 2900 |
| 65CQ-25 | 65 | 50 | 25 | 16.8 | 5.5 | 2900 |
| 65CQ-32 | 65 | 50 | 32 | 25 | 7.5 | 2900 |
| 80CQ-32 | 80 | 65 | 32 | 50 | 11 | 2900 |
| 80CQ-50 | 80 | 65 | 50 | 50 | 15 | 2900 |
| 100CQ-32 | 100 | 80 | 32 | 60 | 15 | 2900 |
| 100CQ-50 | 100 | 80 | 50 | 60 | 18.5 | 2900 |
Company Information:
Gempump is one of the leading centrifugal pump manufacturers and exporters in the field of industry pumps with manufacturing facilities in mainland China. We are specialized in Magnetic Drive Centrifugal pump, slurry pump, water pump, centrifugal pump, stainless steel pump, chemical pump etc.
Q: What type of company Gempump is?
A: Gempump is a centrifugal pump manufacture an trading company, has factories in Shijiazhuang,China, with export and import license.
Q: What kinds of pumps do you supply?
A: Our products including self-priming trash pump, centrifugal pump, slurry pump, submersible pump, chemical pump, stainless steel pump, magnetic drive pump, etc.
Q: What is your payment terms?
A: Western Union, Paypal, T/T, L/C, etc.
Q: Can you provide OEM, ODM service?
A: Yes,we can make pump products according to your requirements.
Q: Why should we buy from you?
A: We are committed to provide best quality pumps products at minimum delivery time and competitive price. We believe this is what customer wants. We are satified until customers are.
Q: What is your warranty period?
A: We provide one year of unconditional warranty on our products for the manufacturing defects.
Q: What about delivery time?
A: Normally our production time is within 5 days. Please confirm before order.
