Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Brand Name: | Gempump |
| Certification: | ISO9001 CE |
| Model Number: | CQB65-40-250F |
| Minimum Order Quantity: | 1 set |
| Price: | 1000 USD/SET |
| Packaging Details: | Ply wooden box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 SET/Month |
| Product: | Acid Proof Magnetic Transfer Pump | Place Of Orign: | China |
|---|---|---|---|
| Application: | Aicd,Alkali,Wastewater Transport | Warranty: | 2 Year |
| Lead Time: | 10 Days | Motor Voltage: | AC220V,AC380V,AC415V |
| Pump Material: | FEP, PFA, PTFE, PVDF, PP | Power: | Electric Motor |
| Structure: | Single Stage Pump | Seal: | Mechanical Seal,no Leakage |
| High Light: | 98% sulfuric acid proof pump,FEP PFA Magnetic Centrifugal Pump,FEP PFA sulfuric acid proof pump |
||
Magnetic Acid Pump Description
1. Capacity:3.4~460m3/h
2. Head:3.6~132m
3. Size:25~250mm
4. Speed:1450~2900r/m
As the over-current part of the pump is made of "fluoroplastic alloy". It can continuously transport any concentration of acid, alkali, strong oxidant and other corrosive media without damage. The pump has unique design, no mechanical shaft seal and absolutely no leakage. The liquid flowing parts are made of fluoroplastics, ceramics, fluororubber and other materials. The shell of the pump body is fixed with metal materials, so the pump body is sufficient to support the weight of the pipeline and is convenient to use and maintain.
Widely applicable to:
Petrochemical industry, acid-making and alkali-making, non-ferrous metal smelting, pickling process for automobile manufacturing, rare earth separation, pesticide, dye, medicine, paper making, electroplating, radio and other industries.
Partial performance parameter table
Centrifugal Magnetci Pump Model:
| TYPE | IN | OUT | Q (m3/h) |
H (m) |
P (kw) |
N(r/min) | n (%) |
V (v) |
NPSHr (m) |
| CQB-15-10-85F | 15 | 10 | 1.8 | 8 | 0.12 | 2900 | 33 | 220/380 | 6.0 |
| CQB-20-15-105F | 20 | 15 | 3.0 | 12 | 0.37 | 2900 | 33 | 220/380 | 6.0 |
| CQB-32-25-125F | 32 | 25 | 3.2 | 20 | 0.75 | 2900 | 35 | 380 | 5.0 |
| CQB-40-32-115F | 40 | 32 | 6.3 | 15 | 0.75 | 2900 | 45 | 380 | 6.0 |
| CQB-40-32-145F | 40 | 32 | 6.3 | 25 | 1.5 | 2900 | 42 | 380 | 5.0 |
| CQB-50-40-125F | 50 | 40 | 12.5 | 20 | 2.2 | 2900 | 47 | 380 | 3.5 |
| CQB-50-40-160F | 50 | 40 | 12.5 | 32 | 3.0 | 2900 | 46 | 380 | 3.5 |
| CQB-65-50-125F | 65 | 50 | 25 | 20 | 3.0 | 2900 | 58 | 380 | 4.0 |
| CQB-65-50-160F | 65 | 50 | 25 | 32 | 4.0 | 2900 | 56 | 380 | 4.0 |
| CQB-80-65-125F | 80 | 65 | 50 | 20 | 7.5 | 2900 | 66 | 380 | 4.0 |
| CQB-80-65-160F | 80 | 65 | 50 | 32 | 11 | 2900 | 64 | 380 | 4.0 |
| CQB-100-80-125F | 100 | 80 | 100 | 20 | 15 | 2900 | 72 | 380 | 4.0 |
| CQB-100-80-160F | 100 | 80 | 100 | 32 | 18.5 | 2900 | 70 | 380 | 4.0 |
Structural Representation
1. How to get our quotation in time, pls answer following questions:
1)What liquid do you transfer? Oil, Water, Food or Corrosive Chemical liquid, with solid particle or not, and so on~
2) What's the flow or capcity (m3/h, L/m)?
3) What's the discharge head (m, feet, Mpa, bar )
If you do not have any request, we will do as our normal standard.
4) Contact us to get the quotation
2.OEM: Ok
3. MOQ: 1set
4. Package: Standar export Plywood Case or Styrofoam with Carton
5. Shipping ways: By sea, By air, By express
6. Lead time: 3-15days
7. Term of payment: 100% T/T, L/C, Westunion
8. Warranty Period: One year, except spare parts
9. Why choose Gempump China:
Decades experiences Pump manufacturer in China.
Good quality with competitive pirce.
ISO9001, CE certificate.
Professional after-sales service.
