Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Brand Name: | Gempump |
| Certification: | ISO9001 CE |
| Model Number: | DG6-25X6 |
| Minimum Order Quantity: | 1 set |
| Price: | 1000 USD/SET |
| Packaging Details: | Ply wooden box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/A, D/P, Western Union |
| Supply Ability: | 1000 SET/Month |
| Product: | Multistage Pump For Mining Industry | Warranty: | 1 Year |
|---|---|---|---|
| Pressure: | High Pressure | Theory: | Multistage Centrifugal |
| Application: | Drinking Water Treatment, Industrial Boilers | Power: | Electric Motor |
| Voltage: | AC220V AC380V AC415V/50HZ | Seal: | Mechanical Seal,Packing Seal |
| High Light: | GB/T5657 Fire Fighting Jockey Pump,6 Stage Diesel Dewatering Pump,6 Stage Diesel Dewatering Pump |
||
Model Instruction
Diesel Fire Fighting Multistage Water Pump Unit Jockey Dewatering Pump Electric
Dewatering Multistage Pump Product Information:
SLD single-suction multi-stage sectional-type centrifugal pump is used to transport the pure water containing no solid grains and the liquid with both physical and chemical natures similar to those of pure water, the temperature of the liquid is not over 80ºC,suitable for water supply and drainage in mines, factories and cities.
Note: Use an explosion-proof motor when used in a coal well.
This series pump complies with the standards of G B/T3 216 and GB/T5657.
This series of pump is of sub-horizontal, multi-stage single-suction and centrifugal, using state-recommended hydromodule. The pump is efficient, reliable, and durable with low noise performance, easy maintenance and wide scope of usage. Our pump is applicable to deliver those fluid without solid, particles or any other suspended stuff, water for instance. While oil and corrosive or solid-contained fulid can be pumped by means of material modification, sealing methods, and cooling system adding.
Features and benefits:
Low noise
Stable running
E.G.: ZD(DG,DF,DY,MD)46-50X(3-12)
D: Self-balancing multistage centrifugal pump for clean water
DG: Self-balancing multistage centrifugal pump for hot water
DF: Self-balancing multistage centrifugal pump for corrosive liquid
DY: Self-balancing multistage centrifugal pump for petrolchemical oil
MD: Self-balancing multistage centrifugal pump for sewage water
46: Rate flow capacity is 46m3/h
50: Rate head of 1 stage is 50m
3-12: Number of stage of the pump is 3-12.
Diesel Fire Fighting Multistage Pump Applications:
Water supply & drainage for mines, factories and cities,Fire fighting.
Technical Data:
Capacity 6.3-450M3/h
Head 22~650m
Temperature of the liquid ≤ 80C
Company Profile:
Shijiazhuang Gempump is a well-known, large-scale group company with diversified businesses. The company is specialized in research and manufacturing of water pumps,slurry pumps, fluid delivery system, electrical control system and environmental friendly equipment.
After ten years of development, the company now has five industrial parks, which are located in Shijiazhuang and other developed areas, covering a total area of 550,000 square meters.
The company has more than 3,000 kinds of products, covering pumps, motors, electrical cabinets, complete equipment, machinery accessories and other products. Its products are of reasonable price and reliable quality and are widely used in municipal, construction, environmental protection, petroleum, mining and many other fields.
The group currently has more than 2,000 sets of advanced domestic and foreign production and testing equipment, such as large pump testing center, trilinear-coordinates measuring instrument, static and dynamic balance meter, laser rapid prototyping meter, multifunction blasting machine, automatic welding machine, large vertical lathe, large grinding machine and CNC machine tools, etc.
Quality Assurance
Our R&D, manufacturing, production and testing facilities are all centrally housed and constantly improved as the most modern and efficient facilities in China. Supplying quality pumps has been the common commitment for all Gempump people.
Gempump Pumps represent a fusion of computer-aided design and manufacturing echniques, guaranteeing you the best performance. To maintain the high standard quality set by Sanlian, all pumps are subjected to stringent inspection at all stage of production. They also comply with the appropriate international quality assurance and inspection standards. As a symbol of this reliability, Sanlian has been accredited with ISO 9001 certification.
Gempump has built up solid reputation by providing performance and quality products to all applications for decades of years, our active involvement in supplying custom engineered pumps have also been proven as an accredited source by our OEM partners.
We continue to take pride of servicing all our customers from different applications with the highest standards products.
