Pumping The Water , Pumping Our Honor
| Place of Origin: | China |
|---|---|
| Brand Name: | Gempump |
| Certification: | ISO9001 CE |
| Model Number: | MP-6R |
| Minimum Order Quantity: | 1 set |
| Price: | 1000 USD/SET |
| Packaging Details: | Ply wooden box |
| Delivery Time: | 5-8 working days |
| Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
| Supply Ability: | 1000 SET/Month |
| Product: | MP Mini Liquid Pump Magnetic Drive Pump | Place Of Orign: | China |
|---|---|---|---|
| Application: | Aicd,Alkali,Wastewater Transport | Warranty: | 2 Year |
| Lead Time: | 10 Days | Motor Voltage: | AC220V,AC380V,AC415V |
| Pump Material: | SS304.SS316.SS316L | Power: | Electric Motor |
| Structure: | Single Stage Pump | Seal: | Mechanical Seal,no Leakage |
| High Light: | MP Mini Magnetic Centrifugal Pump,0.03KW Magnetic Centrifugal Pump,Alkali Resistant Magnetic drive pump |
||
MP Magnetic pump is extraordinarily high efficiencies make WMD & MD the clear choice in almost every process, recirculation or transfer application. Choose standard alumina ceramic bearing materials and polypropylene, or optional SiC (silicon carbide) and ETFE (fluoropolymer) for your most aggressive or highest purity requirement.
MP pumps are compact, quiet, highly efficient pumps for your Laser, Chiller or Blood Analyzer Applications? TEK pumps are compact, offer higher pressure, AND last longer than any traditional offerings.
Motor Matching - Offering more motor/pump configurations than any other manufacturer easily allows tailored pump applications. Premium, high efficiency motors are used throughout the line. Totally enclosed, permanent split capacitor motors are compact, cool and economical. Tolerance to voltage variation without overheating and 50/60 Hz operation allows the product to be used in a worldwide market. PSC or shaded pole AC motors are standard. Brushed and brushless motors are available for DC applications.
Product Power 0.03-2.2KW
| Model | Motor | Hose Size | Screw Joint | Max.Flow | Max.head | Rated Flow | Rated Head | Specific Gravity | |||
| Output | Power | Inlet | Outlet | Suction | Move Hose | ||||||
| (W) | Voltage(V) | (mm) | (mm) | Inch | mm | (L/min) | (m) | (L/min) | (m) | Liquid | |
| MP-6R | 3 | 1-phase | 14 | 14 | G3/4 | 13 | 8/9 | 1/1.4 | 2.8/5 | 0.8 | <1.2 |
| MP-10R | 6 | 1-phase | 14 | 14 | G3/4 | 13 | 11/12 | 1.5/2.1 | 5/8 | 1 | <1.1 |
| MP-15R | 10 | 1-phase | 16 | 16 | G3/4 | 13 | 16/19 | 2.7/3.4 | 6/12 | 1.5 | <1.3 |
| MP-15RN | 10 | 1-phase | 16 | 16 | G3/4 | 13 | 16/19 | 2.7/3.4 | 8/12 | 1.5 | <1.3 |
| MP-20R | 20 | 1-phase | 18 | 18 | G3/4 | 13 | 27/32 | 3.1/4.3 | 17/22 | 2 | <1.2 |
| MP-20RM | 20 | 1-phase | 18 | 18 | G3/4 | 16 | 27/32 | 3.1/4.3 | 30/40 | 1 | <1.2 |
| MP-20RX | 20 | 1-phase | 26 | 26 | G1 | 16 | 46/52 | 1.8/2.5 | 30/40 | 1 | <1.3 |
| MP-20RZ | 20 | 1-phase | 18 | 18 | G3/4 | 16 | 10/11 | 4.6 | 6.97/10 | 2.5 | <1.1 |
| MP-30R | 45 | 1-phase | 20 | 20 | G3/4 | 16 | 33/38 | 3.8/5.4 | 16/25 | 2.5 | <1.3 |
| MP-30RM | 45 | 1-phase | 20 | 20 | G3/4 | 20 | 33/38 | 3.8/5.4 | 16/25 | 2 | <1.3 |
| MP-30RX | 45 | 1-phase | 26 | 26 | G1 | 20 | 62/72 | 2.9/4.1 | 32/46 | 6 | <1.1 |
| MP-30RZ | 45 | 1-phase | 18 | , 18 | G3/4 | 20 | 15/17 | 8/11 | 10/14 | 4 | <1.1 |
Widely used in chemical industry,medicine,construction,Environmental protect,irrigation works,powe industry,Petroleum,Fire control,food,printing,and color Photofinishing,etc.
| Model | MP-6R |
| Tube Interface Inlet | 14mm |
| Tube Interface Outlet | 14mm |
| Max. Capacity | 8L/min(50Hz);9L/min(60Hz) |
| Max.Head | 1M(50Hz);1.4M(60Hz) |
| Standard Capacity | 2.8L/min(50Hz);5L/min(60Hz) |
| Standard Head | 0.8m |
| Specific Gravity | <1.2 |
| Ambient Temperature | 0℃-40℃ |
| Medium Temperature | 0℃-100℃ |
