Place of Origin: | China |
---|---|
Brand Name: | Gempump |
Certification: | ISO9001 CE |
Model Number: | CQB65-40-250F |
Minimum Order Quantity: | 1 set |
Price: | 1000 USD/SET |
Packaging Details: | Ply wooden box |
Delivery Time: | 5-8 working days |
Payment Terms: | L/C, D/A, D/P, T/T, Western Union, MoneyGram |
Supply Ability: | 1000 SET/Month |
Product: | Acid Resistant Magnetic Pump | Place Of Orign: | China |
---|---|---|---|
Application: | Aicd,Alkali,Wastewater Transport | Warranty: | 2 Year |
Lead Time: | 10 Days | Motor Voltage: | AC220V,AC380V,AC415V |
Pump Material: | FEP, PFA, PTFE, PVDF, PP | Power: | Electric Motor |
Structure: | Single Stage Pump | Seal: | Mechanical Seal,no Leakage |
High Light: | PFA Mag Drive Centrifugal Pump,CE Single Stage Magnetic Chemical Pump,FEP Mag Drive Centrifugal Pump |
ISO Acid Resistant Magnetic Drive Circulation Fluorine Plastic Magnetic Pump
Acid Resistant Magnetic Drive Pump Overview:
CQB-F fluorine plastic magnetic pump is usually composed of one motor, one magnetic coupling and one corrosion resistant centrifugal pump. The main working principles:
1. Use the magnetic coupling to transmit the power without any leakage.
2. When the motor drives along with the outer magnet of the magnetic coupling, the magnetic field lines bring along with the inner magnet through the gap and isolated set.
3. The pump rotor synchronously rotates with the motor without losing any power.
The pump is suitable for petroleum, chemical, smelting and electroplating industries, environmental protection, food industries, film developing and printing industries, water treatment and national defense. This is an ideal pump for transporting inflammable, explosive, volatile, toxic, corrosive, rare precious liquid etc.
CQB Pump Model Meaning:
For example: CQB50-30-160
CQB Pump Model:
Model | Capacity Q (m3/h) |
Head (m) |
Speed (r/min) |
Diameter (mm) |
Power (kW) |
|
Inlet | Outlet | |||||
CQB16-12-50F | O.6 | 2 | 2900 | 16 | 12 | 0.025 |
CQB15-15-65F | O.8 | 3.2 | 2900 | 15 | 15 | 0.18 |
CQB20-15-75F | 1.6 | 7 | 2900 | 20 | 15 | 0.18 |
CQB25-20-100F | 2.5 | 10.5 | 2900 | 25 | 20 | 0.37 |
CQB32-20-110F | 5.5 | 13 | 2900 | 32 | 20 | 0.55 |
CQB40-25-120F | 6.3 | 15 | 2900 | 40 | 25 | 0.75 |
CQB40-40-100F | 6 | 11 | 2900 | 40 | 40 | 0.55 |
CQB40-40-125F | 6.5 | 17.5 | 2900 | 40 | 40 | 1.1 |
CQB50-32-125F | 12 | 20 | 2900 | 50 | 32 | 1.5 |
CQB50-32-125FL | 12.5 | 20 | 2900 | 50 | 32 | 2.2 |
CQB50-32-160FL | 12.5 | 32 | 2900 | 50 | 32 | 4 |
CQB50-32-200FL | 12.5 | 50 | 2900 | 50 | 32 | 7.5 |
CQB65-50-150F | 20 | 25 | 2900 | 65 | 50 | 4 |
CQB65-50-160F | 17.5 | 32 | 2900 | 65 | 50 | 4 |
CQB65-50-180F | 8 | 38 | 2900 | 65 | 50 | 5.5 |
CQB65-40-200FL | 25 | 50 | 2900 | 65 | 40 | 11 |
CQB80-60-160FL | 50 | 32 | 2900 | 80 | 65 | 11 |
CQB80-50-200FL | 50 | 50 | 2900 | 80 | 50 | 18.5 |
CQBl00-80-160FL | 100 | 32 | 2900 | 100 | 80 | 22 |
CQB-F China Supplier Fluorine Plastic Magnetic Force Driven Pump
Magnetic Pump Application:
1) It is widely used in chemical, pharmacy, rare dust separate, smelt and car manufacture area.
2) Better for transporting acids, bases, oils and other fluids, which are either toxic and volatile or easy to leak, flammable and explosive.
3) Suitalbe Temperature: -20°C~+100°C
