Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power

China Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power supplier
Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power supplier Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power supplier Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power supplier

Large Image :  Garden Irrigation Booster Single Suction Centrifugal Pump 0.18 - 250kw Motor Power

Product Details:

Place of Origin: Shanghai China
Brand Name: GTOPUMP
Certification: ISO/WSC/CE/SGS
Model Number: ISW Series

Payment & Shipping Terms:

Minimum Order Quantity: 1 set
Price: Negotiable
Packaging Details: plywood carton for export
Delivery Time: 24 working days
Supply Ability: 2058 sets per month
Contact Now
Detailed Product Description
Product Type: Horizontal Split Case Pump Usage: Water Or Oil
Outlet Nominal Diameter: DN15 To DN500mm Head Range: 3 To150m
Motor Power: 0.18 To 250kw Theory: Centrifugal Pump

Horizontal Water Pump Single Suction , Garden Irrigation Booster Pump

Overview:

This Series is Horizontal Single Stage Single Suction Centrifugal Pump. Its design meets the performance and dimension specifications of international ISO2858 standard, making them in parallel with the international andadvanced level in technology. It apply to clean water, and liquid without solid particles, which is similar to water in physical and chemical properties.

Working Condition:

Capacity: 5~2640M3/H With 2950RPM, 1450RPM, 980RPM, 740RPM
Head: 5-135M
Medium Temperature: -20~105
Material: Cast iron-HT200, HT250; SS304; SS316; SS316L, Duplex SS;
ational ISO2858 standard, making them in parallel with the international andadvanced level in technology. It apply to clean water, and liquid without solid particles, which is similar to water in physical and chemical properties.


Model Meaning:
ISW (ISWR,ISWH,ISWY,ISWHY) 100 – 160 (I) A (B)
ISW: horizontal centrifugal pump
ISWR: horizontal hot water centrifugal pump
ISWH: horizontal chemical centrifugal pump
ISWY: horizontal explosion-proof oil pump
ISWHY: horizontal explosion-proof chemical centrifugal pump
100: nominal diameter of pump inlet and outlet (mm)
160: nominal diameter of impeller (mm)
(I): flow classification
A: impeller processed with first cutting
(B): impeller processed with second cutting

Parameters Data:

ModelCapacity
(m3/h)
Head
(m)
Speed
(rpm)
Power
Kw
Voltage
(V)
NPSHr
(m)
65-250A23.470290011.03802.5
65-250B21.660290011.03802.5
65-31525125290030.03802.5
65-315A23.7113290022.03802.5
65-315B22.5101290018.53802.5
65-315C20.685290018.53802.5
65-100(I)5012.529003.03803.0
65-100(I)A44.71029002.23803.0
65-125(I)502029005.53803.0
65-125(I)A451629004.03803.0
65-160(I)503229007.53803.0
65-160(I)A46.72829007.53803.0
65-160(I)B43.32429005.53803.0
65-200(I)5050290015.03803.0
65-200(I)A4744290011.03803.0
65-200(I)B43.53829007.53803.0
65-250(I)5080290022.03803.0
65-250(I)A46.770290018.53803.0
65-250(I)B43.360290015.03803.0
65-315(I)50125290037.03803.0





** Providing more details about your requirement such as flow, head, motor, medium and the like, you will get more correct products and price.
